High Degree of Intelligent Automation
Integrates the washer, dryer, shuttle, weighing machine, inclined loading line, distribution line, and drying output conveyor into one fully automated system. No manual intervention is required for loading and unloading. It features smart task allocation, seamless equipment operation, complete process recording, customer ID tracking, accurate weight measurement, enhanced performance, and stable operation.
Unique Top Loading Mode
Allows simultaneous loading and unloading without interference. Can pre-store more than one load of linens, enabling continuous loading with the fastest load time around 1 minute. Three-stage speed differential disperses and spreads linens, ensuring smooth loading of large items without clogging. Maximizes the use of factory upper space, reduces labor intensity, and speeds up the loading process, thus improving work efficiency.
Rated Dry Linen Loading
Designed with an extra-large diameter loading drum opening, with a rear tilt loading angle of ≥25 degrees and a front tilt unloading angle of ≥21 degrees. Utilizes quick dry material loading technology (no water flushing in the loading hopper) and internal drum spray structure to prevent water leakage, keeping the work environment clean. The loading hopper remains in a fixed direction, driven pneumatically, with no need for positioning.
Modular Combination for Dedicated Washing
Allows flexible configuration according to customer premises, enabling dedicated machines for specific washing needs to avoid mixed washing and optimize space utilization. This ensures categorized washing of different types and colors of linens, resulting in precise and thorough cleaning. The system can still operate normally even if some module functions fail, providing stable operation and easy maintenance.
Automatic Unloading and Fluffing Function
Equipped with an automatic fluffing function to avoid manual intervention during unloading, speeding up the process. Driven by pneumatic cylinders, the floating door structure, and direct push-seal design ensure low failure rates for automatic door opening and closing. Features a unique air circuit design that maintains cylinder position in case of sudden power outages or air hose ruptures, preventing damage and faults.
Intelligent, Efficient, and Energy-Saving
High level of intelligence to improve work efficiency, reduce labor intensity, and save manpower. The shuttle car uses binary encoding for precise and reliable positioning, preventing malfunction. It intelligently detects position distance and automatically adjusts speed and braking for accurate positioning. The L-shaped shuttle design increases the gap and loading capacity between the cage and the shuttle, resulting in looser unloading. The automatic distribution function prevents linen clumping, facilitating efficient dryer feeding.
